* USB Kit: black scanner (MS5145-38-3), 1.5m USB Type A cable (55-55235B-N-3) and documentation

Low cost laser reader
Automatic firing with Code Gate system
PowerLink Cable replaced by the user
Compatible with PAHO and JPOS systems
Supports all common interfaces, including USB

GENERAL
Type: Barcode Scanner - PDA
Width: 6.3 cm
Depth: 16.9 cm
Height: 3.5 cm
Weight: 97 g
Color: Black
Location: Europe
COURSE CODE
Interface type: USB
Minimum bar width: 4 thousand
Width of the exploration field: 49 mm - 195 mm
Type of Exploration Item: Visible Laser Diode
Wave length of a light source: 650 nm
Exploration Mode: One Pass
Exploration speed: 72 line / second
Maximum operating distance: 191 mm
Inclination (degree): 52
Height (degree): 68
Print contrast signal (PCS): 35%
Decoding capacity: Code 93, Matrix 2 of 5, Code 39, UCC/EAN-128, RSS code, Telepen, Code 39 Full ASCII, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, Codabar, Code 128, Code 11, Intercalated 2 of 5, MSI-Plessey
TTL Decoding: Decoding
Connectivity technology: Cable
Notification OK: Audio signal (bip), LED indicator
Properties: Activated
EXPANSION / CONECTIVITY
Interfaces: 1 x USB - 4 PIN USB type A
OTHER
Compliance: FCC Class B Certificate, UL, IEC 825-1/EN 60825-1 class 1, EN55022 Class B, ICES-003 Class B
ALIMENTATION
Power supply: Power adapter - external
STORE PARENTS
Minimum operating temperature: 0 °C
Maximum operating temperature: 40 °C
Operating humidity: 5 - 95%
Fall specification: 1.5 m
