Specifications:

2.4GHz Hi Power 2x2 MIMO AirMax TDMA Station.

More than 150 real Mbps of outdoor performance and a range exceeding 15km. Thanks to technology 2x2 MIMO that uses the new NanoStation, the links are significantly faster and at a distance higher than ever before.

Optimized cross polarization insulation and very compact design.

The new NanoStation M offers a second Ethernet port with the possibility of activating the PoE function by Software for perfect integration with IP Video.

INFORMATION OF THE SYSTEM

Atheros MIPS 24KC processor, 400MHz
Memory 32MB SDRAM, 8MB Flash
Network Interface 2 X 10/100 BASE-TX (Cat. 5, RJ-45) Interface Ethernet

REGULATION/CERTIFICATIONS

Wireless FCC Part 15.247, IC RS210, CE
RoHS

FUNCIONAMIENT

2412MHz-2462MHz

ELECTRIC/ ENVIRONMENTAL DATA

Transmission power: 9dBm (EU ), 28dBm ( Other countries)

Transmission power (PIRE): 20dBm (EU ). 39dBm ( Other countries)

Dimensions of the box 29.4 cm x 8 cm x 3cm
Weight 0.4kg

Case characteristics

Outer box, UV plastic stabilized
Mounting Kit assembly in mast included
Maximum consumption 8 Watts
Power Supply 24V included PoE adapter, 0.5A voltage protection

Passive Power over Ethernet power method (compared 4.5+; 7.8 return)
Operating temperature -30C to +80C
Operating humidity 5 to 95% condensation
Shock and Vibration ETSI300-019-1.4
