Features:
-Complied with ATX and ATX12V standard
-Active Power Factor Correction (PFC) meet EN61000-3-2
-High efficiency and reliability
-Remote ON/OFF function
-Internal 12V DC fan included
-Noise Killer (thermal fan speed control function)
-Low noise and ripple
-Complies with FCC part 15 subpart J class B 115Vac operation, and CISPR 22 class B at 230Vac operation
-Output voltage over, short circuit, and over current protection
-100% Hi-pot, ATE, and burn-in tested
-Re-settable power shut down
-Approved by UL60950-1, CSA C22.2 NO. 60950, TUV EN60950 or VDE EN60950, NEMKO EN60950 (CB Report)

Specification:
-Temperature Range: Operating: 0°C +50°C on load full; storage " shipping ": -20°C +80°C
-Humidity: 5 95% on operating and storage
-Dielectric Withstand: Input to frame ground 1800 VAC for 1 second
-Efficiency: 68% at minimum measured at nominal AC main voltage and frequency with maximum load on all outputs
-Rise time: Less than 20ms
-Hold-up Time: 20ms minimum at nominal input voltage
-Power Good Signal: Power on delay time 100 500ms, off delay 1ms minimum (TTL and CMOS compatible)
-Leakage Current: Not exceed 3.5mA at 264Vac, 50Hz
-MTBF: 100,000 hours on maximum load at +25°C
-Dimensions (WxHxL): 205x100x40.5x205mm/.9x1.6x8in

Input Characteristics:
-Input Range: 90 264Vac (RMS), Full Range Input
-Frequency: 47 63Hz
-Input Current: 5A (RMS) @115Vac, 2.5A (RMS) @230Vac
-Inrush Current: 50A Max @115Vac, 80A Max @230Vac cold start

Output Characteristics:

Compatible with Equipment as :

SonicWall Pro 3060 (1RK09-032)
