Specifications:
Interface 1 Ethernet port RJ4510/100Mbps
Buttons Range Extender
Reset button
Power On/Off button
Power consumption 3W
Antennas 2 5dBi detachable Omnidirectional Antennas (RP-SMA)
Power Supply Externa 9V-0.6A
IEEE 802.11n Wireless Standards, IEEE 802.11g, IEEE 802.11b
Dimensions 181.5*125.7*36.2 mm (7.2*5.0*1.4 in.)
INALABIC CHARACTERISTICS
Frequency 2.42.4835GHz
Signal rate 11n: Up to 300Mbps (dynamic)
11g: Up to 54Mbps (dynamic)
11b: Up to 11Mbps (dynamic)
Reception Sensibility 270M: -68dBm@10% PER
130M: -68dBm@10% PER
108M: -68dBm@10% PER
54M: -68dBm@10% PER
11M: -85dBm@8% PER
6M: -88dBm@10% PER
1M: -90dBm@8% PER
Transmission Power ≥ 20 dBm (PIRE)
Wireless Range Extender, AP Mode
WMM(Wi-Fi Multimedia) Wireless Functions
Wireless MAC Address Filter
Enable/Disable Wireless Radio
Enable/Disable Wireless SSID Broadcast
AP Isolation
Statistics Wireless
Domain Registration Function
WEP 64/128/152-bit
WPA-PSK / WPA2-PSK
OTHER
CE, FCC, RoHS certifications
N TL-WA830RE Wireless Range Extender Package Content
2 Omnidirectional antennas dismountable
Ethernet cable RJ-45
Power supply
CD
Quick installation guide
System requirements Microsoft Windows 98SE, NT, 2000, XP, Vista, Windows 7, Windows 8, Mac OS, NetWare, UNIX or Linux
Environmental Factors Operating temperature: 0°C 40°C (32°F 104°F)
Storage temperature: -40°C 70°C (-40°F 158°F)
Operating humidity: 10% 90% without condensation
Storage humidity: 5% 90% without condensation
