Red PCIe 10/100/1000 32Bits TP-Link TG-3468

Código PCXeon: 17230

Marca: TP-Link | Part Number: TG-3468

Estado: Nuevo | EAN: 6935360000000

TP-Link
Delivery in 24H
Few units
€14.10
11,65 € without VAT
Few units
Producto Original

Benefits:

  • PCIe adapter to 10/100/1000 Mbps
  • 32-bit PCIe interface: saving space inside the computer
  • Wake-on-LAN feature, remote management through the local network

What this product is for

The PCIe Gigabit network adapter at 10/100/1000 Mbps TG-3468 is a highly integrated and affordable 32-bit PCI Gigabit Ethernet solution that is fully compatible with IEEE 802.3, IEEE 802.3u and IEEE 802.3ab.

The PCIe Gigabit TG-3468 adapter is a high performance device designed for high-speed PCI Express bus architecture. Supports and automatically detects 10/100/1000 Mbps network speeds and incorporates functions such as 802.3x and Wake-on-LAN flow control. The PCIe Gigabit TG-3468 network adapter is a highly integrated and affordable Gigabit Ethernet solution that is a good option to upgrade your network.

Features :

  • Wake-on-LAN Support
  • Automatic speed and MDI/MDIX
  • Supports IEEE 802.3x flow control in Full Duplex and Back-Pressure mode in Half Duplex
  • IEEE 802.1p Layer 2 and labeled VLAN IEEE802.1q
  • Supports energy-saving functions when the equipment is off or off
  • DOS/Win98SE/Me/2000/XP/Vista/Linux/Novell Netware

Specifications:

HARDWARE FEATURES
Standards and protocolsIEEE 802.3, 802.3u, 802.3ab, 802.3x, 802.1Q, 802.1p CSMA / CD, TCP / IP
Interfaces32-bit PCI Express
1 port RJ45 to 10/100/1000 Mbps
Media Network10BASE-T: UTP cable category 3, 4, 5 (100 meters maximum)
EIA/TIA-568 100Ω STP (maximum 100 m)
100BASE-TX: UTP cable categories 5, 5e (maximum 100 meters)
EIA/TIA-568 100Ω STP (maximum 100 m)
1000Base-T: UTP cables category 5, 5e (maximum 100 meters)
Data transfer rates10/100/1000Mbps for Half-Duplex mode
20/200/2000Mbps for Full-Duplex mode
LED indicator1000 Mbps liaison/activity status, 100 Mbps link/activity, 10 Mbps link/activity
Flow controlIEEE 802.3x Flow Control (Full-Duplex)
OTHER
CertificationsCE, FCC, RoHS
Package ContentNetwork Adapter Gigabit PCI Express TG-3468
Use CD
Quick installation guide
System requirementsWindows 7 (32/64 bits), Windows Vista (32/64 bits), Windows XP (32/64 bits)
Environmental factorsOperating temperature: 0°C40°C (32°F104°F)
Storage temperature: -40°C70°C (-40°F158°F)
Operating humidity: 10%90% without condensation
Storage humidity: 5%90% without condensation
