High levels of power and reception sensitivity that allow greater coverage. Transfer rates of 150 Mbps that exceed the benefits of 11g devices. Simple encryption of the wireless network with just pressing the QSS button. Includes a 1.5 meter USB extension cable to facilitate your installation. Support Windows 2000 / XP / Vista / 7 .
HARDWARE FEATURES
Interface Mini USB
Button Quick security configuration (QSS) compatible with WPS
Dimensions ( W x D x H ) 3,6 x 2,4 x 1,0 inches (90,8 x 60,8 x 24,5 mm)
Antenna Type Removable, omnidirectional (RP-SMA)
Antenna Gain 5dBi
FEATURES
Wireless Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Frequency 2.400-2.4835GHz
Signal Rate 11n: up to 150 Mbps (dynamic)
11g: up to 54 Mbps(dynamic)
11b: up to 11 Mbps (dynamic)
EIRP ≤20 dBm (EIRP, for countries using CE standards)
(EIRP) for countries using FCC standards
Reception Sensitivity 130M:-68dBm @ 10% PER
108M:-68dBm @ 10% PER
54M:-68dBm @ 10% PER
11M:-85dBm @ 8% PER
6M:-88dBm @ 10% PER
1M:-90dBm @ 8% PER
Wireless Modes Ad-Hoc Modes / Infrastructure
Wireless Security Compatible with 64/128 bit WEP, WPA-PSK/WPA2-PSK
Modulation Technology DBPSK, DQPSK, CCK, OFDM, 16-QAM, 64-QAM
Advanced Functions WMM, Soft AP (for Windows XP / Vista), PSP X-LINK (only for Windows XP), Roaming
OTHERS
Certification CE, FCC, RoHS
Package Contents Wireless adapter TL-WN7200ND
5 dBi omnidirectional detachable antenna
Use CD
Quick installation guide
1.5 m USB extension cable
System Requirements Windows 7(32/64bits), Windows Vista(32/64bits), Windows XP(32/64bits), Windows 2000
Environment Operating temperature: 0°C40°C (32°F104°F)
Storage temperature: -40°C70°C (-40°F158°F)
Operating humidity: 10%90% without condensation
Storage humidity: 5%90% without condensation
High levels of power and reception sensitivity that allow greater coverage. Transfer rates of 150 Mbps that exceed the benefits of 11g devices. Simple encryption of the wireless network with just pressing the QSS button. Includes a 1.5 meter USB extension cable to facilitate your installation. Support Windows 2000 / XP / Vista / 7 .
